Indoor:
CEILING CASSETTE (4 WAY ) TYPE:
SPECIFICATIONS:
MODEL NO : FDT28, FDT36, FDT45, FDT56, FDT71, FDT90, FDT112, FDT140, FDT160.
QUIET SOUND LEVEL : As low as 30 dB(A)
RANGE : 0.8 TR to 4.6 TR
INDIVISUAL FLAP CINTROL SYSTEM : According to room temp. Conditions, four directions of air flow can be controlled by indivisual flap as preferred. As indivisual flap contol is available even after installation, installation area became wider than before.
INBUILT DRAIN PUMP : Water lift-up mechanism.
THINNEST DESIGN : Thanks to new design of heat exchanger from 2 parts to 1 part, the height of indoor unit is reduced drastically.
CEILING CASSETTE (4 WAY ) COMPACT TYPE (600X600) :
SPECIFICATIONS:
MODEL NO: FDTC15, FDTC22, FDTC28, FDTC36, FDTC45, FDTC56 RANGE: 0.4TR to 1.56TR
COMPACT IN SIZE – Corresponds with 600mm x 600mm architectural module ceiling design.
COMFORTABLE AIRFLOW - Wide variation of choice
Built- in condensate drain pump
INDIVISUAL FLAP CONTROL SYSTEM : According to room temp. Conditions, four directions of air flow can be controlled by individual flap as preferred. As individual flap control is available even after installation, installation area became wider than before
CEALING CASSETTE (2 WAY):
SPECIFICATION:
MODEL NO: FDTW28, FDTW45, FDTW56, FDTW71, FDTW90, FDTW112, FDTW140
RANGE: 0.8 TR to 4.0 TR
TRANSPARENT ACCESS HOLE TO DRAIN PAN: Dirt condition of the bottom of a drain pan can be checked through this transparent access hole without removing drain pan.
BUILT- IN condensate drain pump
CEILING CASSETTE 1 WAY TYPE: SPECIFICATION:
MODEL NO: FDTS45, FDTS71
RANGE: 1.28TR & 2.0TR
COMPACT IN SIZE – Height of the machine is 220mm only.
Built- in condensate drain pump
CELLING CASSETTE 1 WAY COMPACT:
SPECIFICATION:
MODEL NO: FDTQ22, FDTQ28, FDTQ36
RANGE: 0.6 TR to 1.0 TR
COMPACT IN SIZE – Corresponds with 600mm x 600mm architectural module ceiling design.
COMPACT DESIGN: Comfortable effective cooling for small rooms, with low fan speed airflow at just 5.4 cubic meter per minute. BUILT- IN: condensate drain pump
DUCT CONNECTED- HIGH STATIC PRESSURE:
SPECIFICATIONS:
MODEL NO: FDU45, FDU56, FDU71, FDU90, FDU112, FDU140, FDU160, FDU224, FDU280
EXTERNAL STATIC PRESSURE CONTROL: External static pressure (E.S.P.) can be increase or decrease in wired remote control.
REDUCTION OF WEIGHT: 6 kg less weight than previous models.
REDUCTION OF SOUND PRESSURE LEVEL: 8 DB less noise than previous models.
WIDE RANGE: 1.6 TR to 8.4 TR
STATIC ADVANTAGE: Availability in a wide range of 50 to 200 pascals. Ideal for Hotel & Apartment Applications.
DUCT CONNECTED- LOW/MIDDLE STATIC PRESSURE:
SPECIFICATIONS
MODEL NO: FDUM22, FDUM28, FDUM36, FDUM45, FDUM56, FDUM71, FDUM90, FDUM112, FDUM140, FDUM160
DESIGN FLEXIBILITY: Expansion of external static pressure
WIDE RANGE: 0.6 TR to 4.6 TR
THIN DESIGN: The height of all FDUM models is only 280 mm.
STATIC ADVANTAGE: Availabilty in a wide range of 50 to 200 pascals. Ideal for Hotel & Apartment Applications
DUCT CONNECTED (THIN)- LOW STATIC PRESSURE SPECIFICATIONS:
MODEL NO: FDUT15, FDUT22, FDUT28, FDUT36, FDUT45, FDUT56, FDUT71
QUIET SOUND LEVEL : As low as 25 dB(A)
RANGE : 0.4 TR to 2.0 TR
DUCT CONNECTED (COMPACT & FLEXIBLE) SPECIFICATIONS
MODEL NO: FDUH22, FDUH28, FDUH36
WIDE RANGE: 0.6 TR to 1.0 TR
THIN DESIGN & LIGHT WEIGHT: The height of all FDUH models is only 257 mm & Weight is only 20 kg.
Ideal for Hotel & Apartment Applications
Wall Mounted Type:
Specifications:
Model No : FDK22, FDK28, FDK36, FDK45, FDK56, FDK71
Low Operation Sound Level: Sound Level as low as 31 dB(A).
Range : 0.6 TR to 2 TR
Innovative Design: New FDK model adopts the air flow design that's proven to minimise resistance in a CFD analysis to achieve uniform air conditioning to the furthest corners of the room.
Flap Control System: Selection of flap position is possible .a flap can be set as different angles.
CEILLING SUSPENDED
MODEL NO: FDE36, FDE45, FDE56, FDE71, FDE112, FDE140
RANGE: 1.0 TR to 4.0 TR
FLAP CONTROL SYSTEM: Selection of flap position is possible. A flap can be set as different angles.
SLIM DESIGN: Slim & Sleek Design Starting at just 28 kg in weight means quick, easy & neat installation.
INSTALLATION WORK ABILITY: Refrigerant Piping can be routed in 3 directions (rear up & right)
FLOOR STANDING 2 WAY TYPE:
SPECIFICATIONS :
MODEL NO: FDFW28, FDFW45, FDFW56
Range : 0.8TR to 1.6TR
EASY MAINTENANCE – Front of unit
QUIET SOUND LEVEL : As low as 30 dB(A)
SOPHISTICATED DESIGN : Choice of wall hanging, floor standing or behind gallery installation is available.
FLAP CONTROL SYSTEM : Selection of flap position is possible. A flap can be set as different angles.
CONVENIENT TO USE OPERATION : Simultaneous lower & upper air outlets or upper outlets can be selected by airflow direction button.
FLOOR STANDING WITH CASING TYPE:
SPECIFICATIONS:
MODEL NO: FDFL71, RANGE : 2.0 TR
EASY MAINTENANCE – Front of unit
COMPACT DESIGN
Suitable for perimeter zone air conditioning
QUIET SOUND LEVEL : As low as 30 dB(A)
Ideal for big offices, shopping malls, banquet halls, RESIDENCE
CONCEALED FLOOR STANDING TYPE (WITHOUT CASING):
SPECIFICATIONS:
MODEL NO: FDFU28, FDFU45, FDFU56, FDFU71
RANGE : 0.8TR to 2.0TR
Gives high class interior design. Installed in skirting wall of perimeter
OUTDOOR-AIR PROCESSING UNIT: SPECIFICATIONS:
MODEL NO: FDU500, FDU850, FDU1300, FDU1800
RANGE : 2.6 TR TO 8.0 TR
COMBINES FRESH AIR TREATMENT & AIR-CONDITIONING SUPPLIED FROM SINGLE SYSTEM Air conditioning and outdoor air processing can be accomplished using a single system
COMPACT DESIGN: Design at just 360 mm in height & high static pressure of 200 pa. Connectivity with outdoor unit 8 to 48 HP.
FRESH AIR VENTILATION AND HEAT EXCHANGE UNIT:
SPECIFICATIONS:
MODEL NO: SAF250, SAF350, SAF500, SAF650, SAF800, SAF1000
AIRFLOW (CUBIC METER PER HOUR): 250 to 1000
KEY FEATURES:
Reduces Airconditioning load
Easy installation in ceiling due to low height
Night time free cooling operation
FRESH AIR DX ASSEMBLY:
SPECIFICATIONS:
MODEL NO: SAF-DX250, SAF-DX350, SAF-DX500, SAF-DX650, SAF-DX800, SAF-DX1000
AIRFLOW (CUBIC METER PER HOUR): 250 to 1000
KEY FEATURES
INTERLOCKING WITH AC IDU
SUPERLINK CONNECTION AVAILABLE
Connectivity with all MHI KX6 outdoor unit .
Return Air Temperature Control or supply air temperature control can be selectable.
